SPS Tester (Gurley Type)

When it comes to testing the strength and durability of paper, board, and flexible packaging materials, manufacturers across the world rely on precision instruments that deliver fast, accurate, and repeatable results. MTech Instruments, a leading bursting strength tester double-head manufacturer in India, has built its reputation on exactly this promise. Based in Roorkee, Uttarakhand, we design and manufacture a complete range of paper and pulp testing equipment, and our bursting strength tester double head is one of the most sought-after machines in the paper, corrugation, and packaging industries today.

This detailed guide explains what the double-head bursting strength tester is, how it works, its key features, technical specifications, applications, and why businesses in India and abroad continue to choose us as their preferred testing equipment partner.

What is a Double-Head Bursting Strength Tester?

A bursting strength tester double head is an advanced testing instrument used to measure the maximum pressure a material such as paper, corrugated board, or flexible packaging film can withstand before it ruptures. Unlike a standard single-head unit, the digital bursting machine pneumatic double-head with a touch screen in India allows two samples to be tested simultaneously, which significantly improves testing speed and laboratory throughput.

This makes the machine especially valuable for quality control departments, paper mills, corrugated box manufacturers, and packaging companies that need to test large volumes of material every day without compromising on accuracy.

Working Principle of the Double Head Bursting Strength Tester

The Pneumatic double-head bursting strength testing machine in India works on a simple yet highly reliable principle. Each test sample is clamped firmly between rubber diaphragms on the instrument. Pneumatic pressure is then applied evenly beneath the diaphragm until the sample ruptures. At the exact moment of failure, the machine records the peak pressure applied, which is displayed digitally in kilopascals (kPa) or kilograms per square centimetre (kg/cm2).

Because the machine features two testing heads, operators can run two samples in parallel, cutting down testing time considerably while maintaining consistent, repeatable accuracy across both readings. The digital touch screen interface further simplifies operation, allowing lab technicians to set parameters, view live readings, and record results with minimal manual effort.

Key Features of MTech Instruments' Bursting Strength Tester Double Head

We manufacture our bursting strength tester digital double head in India with a strong focus on precision engineering, operator convenience, and long-term durability. Some of the standout features include:

• Dual testing heads for simultaneous testing of two samples
• Digital touch screen display for easy operation and real-time result viewing
• Pneumatic clamping system for consistent sample fixing pressure
• Wide pressure measurement range suitable for lightweight paper as well as heavy-duty board and packaging materials
• Sturdy, corrosion-resistant construction built for continuous industrial use
• Compliance with major international testing standards
• User-friendly calibration and maintenance features
• Compact footprint suitable for both production floors and testing laboratories

Whether a business is searching for a double-head digital bursting machine manufacturer, or comparing options among global suppliers, our combination of engineering quality and after-sales support makes us a preferred choice.

Technical Specifications

The table below summarises the key technical specifications of our double-head bursting strength tester (Model MTI-3017):

Parameter	Specification
Model Number	MTI-3017
Pressure Range	0-7 to 0-10 kg/cm2 and 0-35 to 0-40 kg/cm2
Applicable Standards (Bursting Strength)	ISO 2758, TAPPI T403, SCAN P24, APPITA/AS 1301.403, ASTM D774, CPPA D.8, DIN 53141, FEFCO No. 4, NF Q 03-053, JIS 8112
Applicable Standards (Board Bursting Strength)	ISO 2759, TAPPI T807, T810, SCAN P25, APPITA/AS 1301.438, DIN 53141, FEFCO No. 4
Operation	Pneumatic, digital touch screen
Testing Heads	Double (2 simultaneous tests)
Construction	Heavy-duty, industrial grade

Applications of the Double Head Bursting Strength Tester

The double-head bursting strength tester is widely used across industries where packaging integrity and material strength are critical to product safety. Common applications include:

• Paper and paperboard manufacturing units
• Corrugated box and carton manufacturing plants
• Flexible packaging and laminate film producers
• Pulp and paper mills conducting raw material quality checks
• Quality control and R&D laboratories
• Export packaging compliance testing

By providing accurate bursting strength data, manufacturers can ensure that their packaging will protect products during storage, handling, and transportation, reducing the risk of damage and returns.

Why Choose MTech Instruments

We have established ourselves as a trusted bursting strength tester double-head supplier in India for several important reasons:

Testing Accuracy and Product Quality

Every machine that leaves our facility undergoes rigorous quality checks to ensure accurate, repeatable bursting strength readings. This commitment to precision is one of the reasons paper mills, packaging companies, and testing laboratories across India and abroad rely on our equipment.

Compliance with International Standards

As a double-head digital bursting machine exporter and dealer from India, we ensure our machines are built to comply with globally recognised standards including ISO, TAPPI, ASTM, DIN, and FEFCO, so customers can be confident that their test results are accepted internationally.

Durability for Industrial Use

Our machines are engineered using high-grade materials and robust construction, ensuring long service life even under continuous industrial testing conditions.

Strong After-Sales Support

We provide installation assistance, calibration support, spare parts, and responsive customer service, ensuring minimal downtime for customers across India and international markets.

Trusted Export Partner

As a well-established bursting strength tester double-head exporter from India, MTech Instruments regularly exports its testing equipment to Nepal, Bangladesh, the USA, the UK, Canada, Singapore, Dubai, and various countries across Europe. This global reach reflects the trust that international buyers place in our quality and reliability.

We are also recognised as a paper and pulp testing machine equipment manufacturer in India , offering a complete range of instruments that support every stage of paper and packaging quality testing.

Global Export Reach

Our commitment to quality has helped us grow into an internationally recognised supplier. As a double-head digital bursting machine supplier from India, we cater to a diverse customer base, including:

• Nepal and Bangladesh, where paper and packaging industries are rapidly growing
• USA, UK, and Canada, where compliance with ASTM and TAPPI standards is essential
• Singapore and Dubai, key packaging and logistics hubs
• European countries such as Germany, France, Italy, and Spain, where ISO and DIN compliance is critical

This wide export footprint is a testament to the consistent quality, accuracy, and durability we deliver with every bursting strength tester double head manufacturer, supplier, and exporter in India relationship we build.
