Product Description
This instrument is used for determination of freeness of wood fibre ground wood and mechanical pulp. It measures the Canadian Freeness number which is a measurement of the drainage capacity of different pulp types.
It is a useful index of the amount of mechanical treatment given to the pulp With standard screen plate and Plexiglas measuring cylinder for CSF value.
3 grams of OD fibre pulp in aqueous suspension is drained through the fibre mat on a standard perforated screen plate during the test into a funnel provided with a bottom and side orifice.
The filtrate collected in specially graduated measuring cylinder from the side orifice is expressed as a CSF value corresponds to milliliter.
Product Specifications
Its Nozzle and screen plate are calibrated according to relevant standards. Two measuring cylinders are included.
Capacity of the cylinder
1000 ml above the screen plate
The Volume in the Bottom
section of the cone
: 23.5 ± 0.2ml (adjusted by means of
the threaded plug in the side orifice)
Any change in this volume may
affect the calibration.
Slope of the main cone
29o ± 5 min.
Orifices provided in funnel
Two, one at the bottom & other on the side.
Distance between the overflow
lip of the tube (inside the funnel)
and bottom of the funnel section
: 50.8 mm ± 0.75 mm
Note: This is extremely critical and
set precisely at the works.
Size of the perforations in the
: 0.51±.01 mm diameter and no of
holes are 97 per/cm2 screen plate
(TAPPI STANDARD)
Compliance to the following
International Standards
: ISO 5267/2
CPPA C1
BS 6035/2
TAPPI T 227
